RKM-270A
HD/SD Multi-Channel LCD Rack Monitor

A brand-new rack-mount monitor with 2 × 7" LCD screens, which has the same high performance display as LVM-074W. Wide viewing angle IPS LCD with 1024 x 600 resolution. It supports SDI in/out and HDMI input.

RKM-270A Specifications

A brand-new rack-mount monitor with 2 × 7" LCD screens, which has the same high performance display as LVM-074W. Wide viewing angle IPS LCD with 1024 x 600 resolution. It supports SDI in/out and HDMI input.

Display/

Size:7
Resolution:1024 X 600 (16 : 9)
Pixe Pitch:0.15mm
Color Depth:16.7M
Viewing Angle:170°(H) / 170°(V)
Luminance:400cd/m2
Contrast Ratio:800:1
Display Area:154(H) x 90(V) mm

Input/

1 X BNC : Analog Input (Composite)
2 X BNC : 3G-SDI A/B Channel Input
1 X HDMI : HDMI Input

RKM-270A Image
RKM-270A ImageRKM-270A Image

/FPGA Functions

1:1 Pixel Mapping Modes for SD/HD
3G-SDI Level A/B
Audio Level Meter Display
Blue Only
Focus Assist
H/V Delay
Key Lock
Luma(Y') Zone Check
Marker
Mono
Range Error
Time Code Display
UMD
Various Scan Modes
Waveform/Vector
Zoom

/Output

1 X BNC : 3G-SDI Output

Product Catalog for all Broadcast Monitors. Click here to download the Product Catalog for all TVLogic broadcast monitors (Big File)
