SVM-183P : 18.5" 12G-SDI High Brightness Field Monitor
Powerful, Versatile, Field-Ready
Experience brilliant 1500nits high brightness, rugged yet lightweight design, and a complete toolset for professional monitoring.
18.5" 12G-SDI High Brightness Field Monitor
The new SVM-130P and SVM-183P deliver outstanding visibility in any environment with 1500nits high brightness, slim & rugged build, and broadcast-level monitoring features including 12G-SDI in/out, waveform & vectorscope, picture-by-picture, and custom 3D LUTs.
Main Body Dimensions
Main Body 484.8 x 339.50 x 130 (mm) / 19.08 x 13.36 x 5.11 (inch)
Weight 7.1kg / 15.65lbs
Product Highlights
• 1500nits High Brightness Display
• 2 x 12G-SDI Input and Loopout
• 12G-SDI Input to 3G-SDI Downscale Output
• Processed Monitor Output
• Cheese Plates, C-stand Mountable
• Dual Battery Brackets (V-Mount, G-Mount)
• Picture-by-Picture Display
• HDR (PQ, HLG, S-LOG3)
• Custom 3D LUT Import by USB Flash Drive
• Auto Detection of SDI Payload ID
• Image Capture & Overlay
• Waveform (YCbCr, RGB) / Vector Scope / Histogram
• Audio Level Meter / Audio Phase Meter
• Fast Mode
• Focus Assist / Marker
• Blue/Mono Only / Timecode Display
• Remote Control & FW Update via Ethernet
• H Flip, V Flip
